PFPD-2R – PowerFit 400A Panel Drain Connector (L2), Red
400A single-pole panel drain connector. IP67, push-and-twist lock, M12 threaded post, TÜV certified.
- Amperage rating: 400A maximum
- Voltage rating: 1000V AC, 1500V DC maximum
- Contact: M12 threaded post, max 12 – 14 N/meter nut torque
- Connection type: Push-and-twist
- Connector type: Single-pole, panel mount, drain (female contact)
- Housing: High impact-resistant thermoplastic, UL94-V0
- Contact material: Brass (silver-plated)
- Panel mount: 42 × 42mm cut-out, 4 × Ø5.5mm fixing holes
- IP rating: IP67 while mated
- Compatibility: Compatible with major brands of single-pole power connector
- Certifications: TÜV Rheinland (ID 1111303479), CE, RoHS, REACH
Learn more
TÜV Rheinland certified (ID 1111303479): Type Approved, Safety, Regular Production Surveillance. CE marked. RoHS and REACH compliant. Flame Class UL94-V0. IP67 rated while mated. Silicone O-ring seal. Brass nut and washer. Working temperature: 45°C to 85°C. Mating cycle: 500.
Compatible with major brands of single-pole power connector systems. The push-and-twist mating mechanism ensures reliable connection geometry and secure locking across standardized suppliers, enabling integration into existing power distribution infrastructure.
Best suited for:
Electrical enclosures requiring secure panel-mounted termination points, switchgear assemblies and power distribution cabinets, generator and UPS distribution panels, outdoor installations where weather resistance and IP67 protection are required, industrial plant power management, and renewable energy systems requiring robust equipment termination.
Product Description
Film and television production facilities operating under North American electrical code standards require permanent power infrastructure that delivers 400A across secondary phase circuits to lighting rigs, camera equipment systems, and support infrastructure mounted in outdoor stages and soundstage electrical rooms. The PowerFit 400A Panel Drain connector in red (Phase 2 / L2 NEC) provides the enclosure-mount architecture for secondary phase distribution in production facility switchboards, enabling rapid reconfiguration during multi-day shoot schedules while maintaining the structural integrity demanded by UL94-V0 rated thermoplastic construction. The patent key-release pin simplifies hot-swap maintenance operations, while the plastic end cap prevents accidental contact with live electrical surfaces during crowded equipment bay work.
Key Features
- 400A continuous current rating at 120mm² cable; 660A at 240mm² cable for multi-rig film production distribution
- Female contact design ensures reliable mating with Panel Source connectors across consecutive shoot days
- M12 threaded post with brass nut and spring washer provides secure fastening in soundstage cabinet installations
- Four diameter 5.5mm fixing holes (42mm × 42mm cut-out) accommodate standard North American electrical cabinet frames
- Patent key-release pin enables production electricians to safely disconnect feeds between take configurations without tools
- Plastic end cap over female contact provides IP 2X finger protection in high-traffic production cable management areas
- Push-and-twist locking mechanism resists accidental separation from equipment movement and vibration
- Silver-plated brass contact delivers 0.1 milliohms contact resistance, minimizing voltage drop across extensive grid lighting systems
- Non-conductive UL94-V0 thermoplastic housing meets North American motion picture safety standards
- IP67 rating while mated provides protection against water ingress from outdoor weather conditions and studio spray cooling systems
- Maximum nut torque: 12 to 14 N/meter ensures secure mounting without risk of rework during shoot schedules
- Red color codes as Phase 2 (L2) under NEC, providing standard phase identification for North American production crews
Certifications & Standards
- TÜV Rheinland certified (ID 1111303479) for North American production facility electrical systems
- CE marking for international production equipment certification
- RoHS and REACH compliant for environmental responsibility in production operations
- UL94-V0 flame retardancy rating for motion picture safety standards
- IP67 rating (dust-tight, submersion-resistant) suitable for outdoor stage and studio installations
- 1000V AC / 1500V DC maximum operating voltage; 4500V AC dielectric test
- Short circuit rating: Up to 35.5kA; insulation resistance greater than 5000 megohms at 500V AC
- Working temperature range: 45 to 85 degrees Celsius—stable across production facility temperature control ranges
Applications
- Film and television soundstage permanent switchboard installations serving multiple lighting and power grids
- Outdoor stage power distribution enclosures for concert touring and event production facilities
- Production support equipment distribution (air conditioning, water systems, safety equipment) in production villages
- Camera truck and mobile production facility power interconnection systems
- Lighting truck trailer permanent power distribution panels for multi-camera field shoots
- Studio generator paralleling switchboards for seamless power backup during live broadcast productions
- Post-production facility power management for editing suites and audio mixing systems
Compatibility
The PowerFit 400A Panel Drain connector is compatible with major brands of single-pole power connector systems used in North American film and television production infrastructure. Its M12 threaded post interface and push-and-twist mating mechanism follow standardized connection geometry across certified suppliers. Verify that your Panel Source connector carries production-grade certifications and matches your facility power specifications. The color-coded red housing complies with NEC phase identification standards used throughout North American motion picture and broadcast industry electrical systems.
Phase / Wire Color Convention
| Region | L1 | L2 | L3 | N | Ground |
|---|---|---|---|---|---|
| NA 120/208V 1 | Green / G-Y | ||||
| NA 277/480V 2 | Green / G-Y | ||||
| IEC 60446 3 | Green-Yellow | ||||
| AU/NZ Legacy 4 | Green-Yellow | ||||
| China 5 | Green-Yellow |
1 North America 120/208V (NEMA / NEC) 2 North America 277/480V (NEMA / NEC) 3 Europe, UK, Australia (current IEC 60446)
4 Australia / New Zealand legacy (pre-IEC) 5 China (GB 50303) G-Y = Green-Yellow (earth/ground)
Frequently Asked Questions
PFPD-2R FAQ
What is PFPD-2R and where is it permanently installed?
PFPD-2R is a KUPO PowerFit 400A panel drain connector with a red housing, identifying Line 2 (L2) under North America (NEC) conventions. Mounted permanently in enclosures and distribution boxes, it serves as the final destination in the PowerFit electric direction flow, where incoming power from Line Source connectors enters the downstream equipment. The four-point flange mount and M12 threaded post ensure vibration-resistant installation. It is commonly deployed in construction site applications. Construction power distribution deals with dust, debris, rain, rough handling by crews, and the constant repositioning of equipment as the site evolves.
What current and voltage ratings make PFPD-2R suitable for permanent distribution?
PFPD-2R is rated for 400 amperes continuous with 120mm2 cable, scaling to 660 amperes with 240mm2 cable. The maximum voltage rating is 1000V AC or 1500V DC. The insulation resistance exceeds 5000 megaohms at 500V AC, and the test voltage rating of 4500V AC provides substantial safety margin. The short circuit rating of up to 35.5 kiloamperes means the connector can withstand fault conditions without catastrophic failure.
How does the red color coding on PFPD-2R help identify L2 on the jobsite?
Red marks Line 2 (L2) under North American NEC conventions. In a standard three-phase system, the color sequence is black (L1), red (L2), blue (L3). Red L2 is one of the most commonly ordered phase variants for US and Canadian power distribution, appearing in virtually every multi-phase temporary power installation. On the Panel Drain, the red color is visible on the connector face that protrudes from the enclosure panel. When multiple PowerFit connectors are mounted side by side in a distribution box, the color-coded faces create a clear visual map of the phase layout for incoming connections. Red is one of the most visually distinctive colors on a busy event site, helping crews quickly trace the second phase conductor even from a distance.
How does PFPD-2R meet safety requirements for panel-mounted power distribution?
PFPD-2R is TUV Rheinland certified (ID 1111303479) under Type Approval, Safety, and Regular Production Surveillance categories. It also carries CE marking, RoHS compliance (Restriction of Hazardous Substances), and REACH compliance. The housing material achieves a UL94-V0 flammability rating, which is the highest classification for vertical flame resistance in plastics, meaning the material self-extinguishes within 10 seconds with no flaming drips. For permanent installations, the IP 2X finger protection prevents accidental contact with live parts when the connector face is exposed, and the four-point flange mount exceeds mechanical retention requirements.
Can PFPD-2R work alongside connectors from other brands in a distribution panel?
PowerFit connectors are designed to be compatible with major brands of single-pole power connector. The high-impact thermoplastic housing absorbs punishment, the IP67 seal protects against dust ingress (the '6' in IP67 means dust-tight), and the M40 cable gland secures cables against pull-out. For L2 circuits using North America (NEC) color conventions, the red PFPD-2R ensures that phase identification remains consistent when mixing PowerFit connectors with existing inventory.
What are the mounting requirements for PFPD-2R in a panel?
Installing PFPD-2R requires a 42 x 42mm cutout in the enclosure panel. The connector mounts through four 5.5mm fixing holes on its flange, distributing clamping force evenly for vibration resistance. The M12 threaded post accepts the brass nut and washer, tightened to a maximum of 12 to 14 N/m. IP 2X finger protection is built into the connector face, preventing accidental contact with live parts when no mating connector is inserted. A plastic end cap protects the contacts during storage and transport. The Panel Drain has a 55.0mm flange width and 72.2mm total depth, with a 37.0mm body diameter. The flange provides a generous mounting surface for secure enclosure attachment.
Video and Download
PFPD-2R — Download Spec Sheet (PDF) ↓
