KL-150LFB – K-LOK 150A Female CAM-Type Line Connector, Blue
150A single-pole female line connector in Blue. CAM-type compatible, cRUus Listed.
- Amperage rating: 150A maximum
- Voltage rating: 600V AC/DC maximum
- Terminal accommodation: #8 – #2 AWG
- Connection type: Double set screws
- Connector type: Single-pole, inline, female
- Housing material: Santoprene TPV, rated to 105°C
- Contact material: Brass
- Retaining screw: Non-conductive POM (Polyoxymethylene)
- Compatibility: Intermates with standard CAM-type connectors
- Listings: cRUus Listed (UL/cUL) — File E332947
- Environment rating: UL Enclosure Types 3R
- Flame class: HB / UL94
Learn more
cRUus Listed (UL and cUL), File Number E332947, tested to UL 1691 — Standard for Safety for Cam-Type, Locking-Type Separable Connectors. Environment rated to UL Enclosure Types 3R. Flame Class HB / UL94. RoHS compliant.
Intermates with standard CAM-type single-pole connectors from all major manufacturers, enabling seamless integration into existing power distribution systems without requiring a full infrastructure change.
Best suited for:
Concert touring and live event production, film, television, and studio power distribution, temporary construction site power, theme park and entertainment venue installations, trade shows and exhibition power systems, industrial temporary power connections, and broadcast and outside broadcast (OB) van power
Product Description
The KUPO K-LOK 150A Female Line Connector is engineered for heavy-duty reliability and safety in temporary power distribution. Featuring a Santoprene TPV (Thermoplastic Vulcanizate) housing rated to 105 degrees Celsius, brass contacts for superior conductivity, and a non-conductive POM (Polyoxymethylene) retaining screw that eliminates accidental current paths, this connector delivers the mechanical strength and electrical performance demanded by professional entertainment and industrial applications. The modular, tool-free design enables rapid field assembly and disassembly, while full interoperability with standard CAM-type connectors ensures seamless integration into existing power distribution systems.
Key Features
- Non-conductive POM (Polyoxymethylene) retaining screw locks the brass contact firmly in position, eliminating accidental current paths for safer operation
- POM insulation sleeve adds heat resistance and structural strength to the contact assembly
- Ribbed Santoprene TPV housing provides a secure, slip-free grip even when wearing work gloves
- Alignment arrow ensures correct orientation for fast, error-free mating every time
- Santoprene TPV housing rated to 105 degrees Celsius withstands demanding site conditions and extreme temperatures
- Brass contacts deliver reliable, low-resistance electrical connections for sustained high-current loads up to 150A
- Double set screw termination provides redundant cable retention for maximum security under vibration and load
- Universal CAM-type compatibility integrates seamlessly with existing power infrastructure from multiple manufacturers
- cRUus Listed (UL/CSA) ensures compliance with North American safety standards
Certifications & Standards
- cRUus Listed (UL and cUL) — File Number E332947
- UL 1691 — Standard for Safety for Cam-Type, Locking-Type Separable Connectors
- Environment Rating: UL Enclosure Types 3R
- Flame Class: HB / UL94
- RoHS (Restriction of Hazardous Substances) Compliant
Applications
- Concert touring and live event production
- Film, television, and studio power distribution
- Temporary construction site power
- Theme park and entertainment venue installations
- Trade shows and exhibition power systems
- Industrial temporary power connections
- Broadcast and outside broadcast (OB) van power
Compatibility
The K-LOK 150A Female In-Line Connector intermates with standard CAM-type single-pole connectors from all major manufacturers, enabling seamless integration into existing power distribution systems without requiring a full infrastructure change.
Phase / Wire Color Convention
| Region | L1 | L2 | L3 | N | Ground |
|---|---|---|---|---|---|
| NA 120/208V 1 | Green / G-Y | ||||
| NA 277/480V 2 | Green / G-Y | ||||
| IEC 60446 3 | Green-Yellow | ||||
| AU/NZ Legacy 4 | Green-Yellow | ||||
| China 5 | Green-Yellow |
1 North America 120/208V (NEMA / NEC) 2 North America 277/480V (NEMA / NEC) 3 Europe, UK, Australia (current IEC 60446)
4 Australia / New Zealand legacy (pre-IEC) 5 China (GB 50303) G-Y = Green-Yellow (earth/ground)
Frequently Asked Questions
KL-150LFB FAQ
Who should use KL-150LFB and why?
Lighting technicians, electricians, and power distribution professionals working with 150A temporary power systems will benefit from KL-150LFB. Its blue housing provides instant visual phase identification, while the Santoprene TPV (Thermoplastic Vulcanizate) housing rated to 105 degrees Celsius ensures durability in demanding field conditions.
What voltage and amperage is KL-150LFB rated for?
KL-150LFB carries a maximum rating of 150A and 600V AC/DC. It accepts wire gauges from #8 to #2 AWG, making it suitable for the conductor sizes typically used in 150-amp power distribution circuits.
Why choose the blue version of the K-LOK 150A female line connector?
In North America, blue designates Phase C (L3), completing the three-phase color set. Under IEC 60446, blue is reserved for the Neutral conductor — making this color essential for international projects and cross-border equipment pools. Choosing KL-150LFB in blue ensures your power distribution system follows established color conventions, speeding up setup and reducing wiring errors.
Is KL-150LFB UL listed and what does that mean?
Yes. KL-150LFB carries cRUus listing (both UL and cUL) under File Number E332947, meaning it has been independently tested and certified to UL 1691 safety standards by a Nationally Recognized Testing Laboratory. This certification is required for professional power distribution in most North American jurisdictions.
What industries commonly use KL-150LFB?
KL-150LFB is widely used in broadcast operations and outside broadcast (OB) van power distribution. Its 150A / 600V AC/DC rating, combined with CAM-type universal compatibility and blue phase coding, makes it a versatile choice across the entertainment, construction, and industrial sectors.
What housing material is used in KL-150LFB and why does it matter?
KL-150LFB uses a Santoprene TPV (Thermoplastic Vulcanizate) housing rated to 105 degrees Celsius. Santoprene TPV combines the flexibility of rubber with the processing advantages of thermoplastic, delivering excellent chemical resistance, UV stability, and durability under repeated mechanical stress — exactly what professional power connectors face on tour and on set.
Video and Download
KL-150LFB — Download Spec Sheet (PDF) ↓
