KL-400SSFB – K-LOK 400A Female CAM-Type Panel Mount Receptacle, Double Set Screw, Blue
400A single-pole female panel mount receptacle (double set screw) in Blue. CAM-type compatible, cRUus Listed.
- Amperage rating: 400A maximum
- Voltage rating: 600V AC/DC maximum
- Terminal accommodation: #6 – 4/0 AWG
- Connection type: Double set screws
- Connector type: Single-pole, panel mount receptacle, female (double set screw)
- Housing material: Santoprene TPV, rated to 105°C
- Contact material: Brass
- Compatibility: Intermates with standard CAM-type connectors
- Listings: cRUus Listed (UL/cUL) — File E332947
- Environment rating: UL Enclosure Types 3R
- Flame class: HB / UL94
Learn more
cRUus Listed (UL and cUL), File Number E332947, tested to UL 1691 — Standard for Safety for Cam-Type, Locking-Type Separable Connectors. Environment rated to UL Enclosure Types 3R. Flame Class HB / UL94. RoHS compliant.
Intermates with standard CAM-type single-pole connectors from all major manufacturers, enabling seamless integration into existing power distribution systems without requiring a full infrastructure change.
Best suited for:
Concert touring and live event production, film, television, and studio power distribution, temporary construction site power, theme park and entertainment venue installations, trade shows and exhibition power systems, industrial temporary power connections, and broadcast and outside broadcast (OB) van power
Product Description
The KUPO K-LOK 400A Female Panel Mount Receptacle (Double Set Screw Type) is engineered for secure, permanent installation in high-current power distribution enclosures and panel assemblies where double set screw termination is preferred. Featuring a Santoprene TPV (Thermoplastic Vulcanizate) housing rated to 105 degrees Celsius, brass contacts for superior conductivity, and a double set screw connection for robust cable retention, this connector delivers the structural integrity and electrical performance required by large-scale entertainment productions and industrial power systems handling up to 400 amperes. Full interoperability with standard CAM-type connectors ensures seamless integration into existing power distribution infrastructure.
Key Features
- Double set screw panel-mount design provides redundant cable retention for maximum security in permanent installations
- Santoprene TPV housing rated to 105 degrees Celsius withstands demanding conditions in fixed enclosure installations
- Brass contacts deliver reliable, low-resistance electrical connections for sustained high-current loads up to 400A
- Double set screw termination accommodates #6 AWG (American Wire Gauge) to 4/0 AWG conductors
- Mounting holes enable secure attachment to enclosures, distro boxes, and panel assemblies
- Universal CAM-type compatibility integrates seamlessly with existing inline connectors from multiple manufacturers
- cRUus Listed (UL/CSA) ensures compliance with North American safety standards
Certifications & Standards
- cRUus Listed (UL and cUL) — File Number E332947
- UL 1691 — Standard for Safety for Cam-Type, Locking-Type Separable Connectors
- Environment Rating: UL Enclosure Types 3R
- Flame Class: HB / UL94
- RoHS (Restriction of Hazardous Substances) Compliant
Applications
- Concert touring and live event production
- Film, television, and studio power distribution
- Temporary construction site power
- Theme park and entertainment venue installations
- Trade shows and exhibition power systems
- Industrial temporary power connections
- Broadcast and outside broadcast (OB) van power
Compatibility
The K-LOK 400A Female Panel Mount Receptacle intermates with standard CAM-type single-pole connectors from all major manufacturers, enabling seamless integration into existing power distribution systems without requiring a full infrastructure change.
Phase / Wire Color Convention
| Region | L1 | L2 | L3 | N | Ground |
|---|---|---|---|---|---|
| NA 120/208V 1 | Green / G-Y | ||||
| NA 277/480V 2 | Green / G-Y | ||||
| IEC 60446 3 | Green-Yellow | ||||
| AU/NZ Legacy 4 | Green-Yellow | ||||
| China 5 | Green-Yellow |
1 North America 120/208V (NEMA / NEC) 2 North America 277/480V (NEMA / NEC) 3 Europe, UK, Australia (current IEC 60446)
4 Australia / New Zealand legacy (pre-IEC) 5 China (GB 50303) G-Y = Green-Yellow (earth/ground)
Frequently Asked Questions
KL-400SSFB FAQ
Who should use KL-400SSFB and why?
Lighting technicians, electricians, and power distribution professionals working with 400A temporary power systems will benefit from KL-400SSFB. Its blue housing provides instant visual phase identification, while the Santoprene TPV (Thermoplastic Vulcanizate) housing rated to 105 degrees Celsius ensures durability in demanding field conditions.
What voltage and amperage is KL-400SSFB rated for?
KL-400SSFB carries a maximum rating of 400A and 600V AC/DC. It accepts wire gauges from #6 to 4/0 AWG, making it suitable for the conductor sizes typically used in 400-amp power distribution circuits.
Why choose the blue version of the K-LOK 400A female panel mount receptacle?
In North America, blue designates Phase C (L3), completing the three-phase color set. Under IEC 60446, blue is reserved for the Neutral conductor — making this color essential for international projects and cross-border equipment pools. Choosing KL-400SSFB in blue ensures your power distribution system follows established color conventions, speeding up setup and reducing wiring errors.
Is KL-400SSFB UL listed and what does that mean?
Yes. KL-400SSFB carries cRUus listing (both UL and cUL) under File Number E332947, meaning it has been independently tested and certified to UL 1691 safety standards by a Nationally Recognized Testing Laboratory. This certification is required for professional power distribution in most North American jurisdictions.
What industries commonly use KL-400SSFB?
KL-400SSFB is widely used in industrial temporary power connections for manufacturing and processing facilities. Its 400A / 600V AC/DC rating, combined with CAM-type universal compatibility and blue phase coding, makes it a versatile choice across the entertainment, construction, and industrial sectors.
How is KL-400SSFB installed in a power distribution enclosure?
KL-400SSFB uses a double set screw panel-mount design with dedicated mounting holes for secure attachment to enclosures and distro boxes. The double set screw termination provides redundant cable retention — two independent screws clamp the conductor, so even if one loosens under vibration, the connection remains intact.
