PFPD-3BL – PowerFit 400A Panel Drain Connector (L3), Blue
400A single-pole panel drain connector. IP67, push-and-twist lock, M12 threaded post, TÜV certified.
- Amperage rating: 400A maximum
- Voltage rating: 1000V AC, 1500V DC maximum
- Contact: M12 threaded post, max 12 – 14 N/meter nut torque
- Connection type: Push-and-twist
- Connector type: Single-pole, panel mount, drain (female contact)
- Housing: High impact-resistant thermoplastic, UL94-V0
- Contact material: Brass (silver-plated)
- Panel mount: 42 × 42mm cut-out, 4 × Ø5.5mm fixing holes
- IP rating: IP67 while mated
- Compatibility: Compatible with major brands of single-pole power connector
- Certifications: TÜV Rheinland (ID 1111303479), CE, RoHS, REACH
Learn more
TÜV Rheinland certified (ID 1111303479): Type Approved, Safety, Regular Production Surveillance. CE marked. RoHS and REACH compliant. Flame Class UL94-V0. IP67 rated while mated. Silicone O-ring seal. Brass nut and washer. Working temperature: 45°C to 85°C. Mating cycle: 500.
Compatible with major brands of single-pole power connector systems. The push-and-twist mating mechanism ensures reliable connection geometry and secure locking across standardized suppliers, enabling integration into existing power distribution infrastructure.
Best suited for:
Electrical enclosures requiring secure panel-mounted termination points, switchgear assemblies and power distribution cabinets, generator and UPS distribution panels, outdoor installations where weather resistance and IP67 protection are required, industrial plant power management, and renewable energy systems requiring robust equipment termination.
Product Description
Three-phase industrial power systems operating across multiple electrical standards require universal phase identification that transcends regional color-coding variations. The PowerFit 400A Panel Drain connector in blue (Phase 3 / L3 universal) provides the enclosure-mount architecture for tertiary phase distribution in multinational manufacturing complexes, pharmaceutical production facilities, and automotive assembly lines where equipment sourced from Europe, North America, and Asia coexists on the same electrical infrastructure. Rated for 400A continuous current at 120mm² cable, this connector delivers the patent key-release pin for safe maintenance disconnection and plastic end cap protection, enabling technicians working across multiple jurisdictions to confidently identify and connect Phase 3 distribution without regional color confusion.
Key Features
- 400A continuous current rating at 120mm² cable; 660A at 240mm² cable for three-phase multinational systems
- Female contact design ensures secure mating with Panel Source connectors in international manufacturing facilities
- M12 threaded post with brass nut and spring washer provides reliable fastening across temperature and humidity extremes
- Four diameter 5.5mm fixing holes (42mm × 42mm cut-out) accommodate international electrical cabinet standards
- Patent key-release pin enables technicians working across multiple jurisdictions to safely disconnect Phase 3 feeds
- Plastic end cap over female contact provides IP 2X finger protection in multi-shift industrial production environments
- Push-and-twist locking mechanism prevents vibration-induced separation from heavy machinery operation
- Silver-plated brass contact delivers 0.1 milliohms contact resistance across high-duty-cycle industrial processes
- Non-conductive UL94-V0 thermoplastic housing meets international electrical safety standards
- IP67 rating while mated protects against coolant spray, moisture, and dust in machine tool environments
- Maximum nut torque: 12 to 14 N/meter ensures secure mounting across thermal cycling conditions
- Blue color provides universal Phase 3 identification across IEC, NEC, Australian, and UK electrical standards
Certifications & Standards
- TÜV Rheinland certified (ID 1111303479) for global multinational manufacturing compliance
- CE marking for European facility distribution
- RoHS and REACH compliant for international environmental responsibility
- UL94-V0 flame retardancy rating for industrial manufacturing safety
- IP67 rating (dust-tight, temporary submersion protection) suitable for machine tool environments
- 1000V AC / 1500V DC maximum operating voltage; 4500V AC dielectric test
- Short circuit rating: Up to 35.5kA; insulation resistance greater than 5000 megohms at 500V AC
- Working temperature range: 45 to 85 degrees Celsius—stable across climate-controlled and non-climate-controlled facilities
Applications
- Multinational manufacturing plant three-phase power distribution with mixed-source equipment
- Pharmaceutical production and clean-room facility tertiary phase interconnection
- Automotive assembly line electrical distribution for robotic welding and machining systems
- Semiconductor fabrication facility process equipment power management
- Heavy industrial plant switchboard and motor control center tertiary phase connections
- International data center backup power systems using multinational three-phase infrastructure
- Food processing and beverage production facility electrical distribution systems
Compatibility
The PowerFit 400A Panel Drain connector is compatible with major brands of single-pole power connector systems used in multinational industrial manufacturing environments. Its M12 threaded post interface and push-and-twist mating mechanism follow standardized connection geometry across certified suppliers worldwide. Verify that your Panel Source connector carries global certifications (TÜV, CE, other international marks) and is rated for your specific installation voltage and amperage. The blue color housing provides universal Phase 3 identification across all major electrical standards, simplifying international facility operations.
Phase / Wire Color Convention
| Region | L1 | L2 | L3 | N | Ground |
|---|---|---|---|---|---|
| NA 120/208V 1 | Green / G-Y | ||||
| NA 277/480V 2 | Green / G-Y | ||||
| IEC 60446 3 | Green-Yellow | ||||
| AU/NZ Legacy 4 | Green-Yellow | ||||
| China 5 | Green-Yellow |
1 North America 120/208V (NEMA / NEC) 2 North America 277/480V (NEMA / NEC) 3 Europe, UK, Australia (current IEC 60446)
4 Australia / New Zealand legacy (pre-IEC) 5 China (GB 50303) G-Y = Green-Yellow (earth/ground)
Frequently Asked Questions
PFPD-3BL FAQ
What kind of installations require PFPD-3BL?
PFPD-3BL is a KUPO PowerFit 400A panel drain connector with a blue housing, identifying Line 3 (L3) under Multiple conventions (NEC, Australian, UK Old) conventions. Mounted permanently in enclosures and distribution boxes, it serves as the final destination in the PowerFit electric direction flow, where incoming power from Line Source connectors enters the downstream equipment. The four-point flange mount and M12 threaded post ensure vibration-resistant installation. It is commonly deployed in emergency and disaster response applications. Emergency power deployment happens in the worst possible conditions: flooded areas, debris fields, extreme weather.
What current and voltage ratings make PFPD-3BL suitable for permanent distribution?
PFPD-3BL is rated for 400 amperes continuous with 120mm2 cable, scaling to 660 amperes with 240mm2 cable. The maximum voltage rating is 1000V AC or 1500V DC. The insulation resistance exceeds 5000 megaohms at 500V AC, and the test voltage rating of 4500V AC provides substantial safety margin. The short circuit rating of up to 35.5 kiloamperes means the connector can withstand fault conditions without catastrophic failure.
How does the blue color coding on PFPD-3BL help identify L3 on the jobsite?
Blue as L3 enjoys unusually broad cross-convention agreement. It represents L3 in North American NEC (black/red/blue), Australian (red/white/blue), and old UK (red/yellow/blue) standards. This makes blue L3 one of the most universally understood phase colors in the world. On the Panel Drain, the blue color is visible on the connector face that protrudes from the enclosure panel. When multiple PowerFit connectors are mounted side by side in a distribution box, the color-coded faces create a clear visual map of the phase layout for incoming connections. The dual identity of blue (L3 in NEC/Australian vs Neutral in IEC) makes proper phase-encoded labeling essential on international projects.
How does PFPD-3BL meet safety requirements for panel-mounted power distribution?
PFPD-3BL is TUV Rheinland certified (ID 1111303479) under Type Approval, Safety, and Regular Production Surveillance categories. It also carries CE marking, RoHS compliance (Restriction of Hazardous Substances), and REACH compliance. The housing material achieves a UL94-V0 flammability rating, which is the highest classification for vertical flame resistance in plastics, meaning the material self-extinguishes within 10 seconds with no flaming drips. For permanent installations, the IP 2X finger protection prevents accidental contact with live parts when the connector face is exposed, and the four-point flange mount exceeds mechanical retention requirements.
What are the mounting requirements for PFPD-3BL in a panel?
Installing PFPD-3BL requires a 42 x 42mm cutout in the enclosure panel. The connector mounts through four 5.5mm fixing holes on its flange, distributing clamping force evenly for vibration resistance. The M12 threaded post accepts the brass nut and washer, tightened to a maximum of 12 to 14 N/m. IP 2X finger protection is built into the connector face, preventing accidental contact with live parts when no mating connector is inserted. A plastic end cap protects the contacts during storage and transport. The Panel Drain has a 55.0mm flange width and 72.2mm total depth, with a 37.0mm body diameter. The flange provides a generous mounting surface for secure enclosure attachment.
What sets PFPD-3BL apart from conventional panel-mount power connectors?
PFPD-3BL offers several meaningful improvements over conventional single-pole power connectors: IP 2X finger protection prevents accidental contact with live parts when the connector face is exposed; IP67 protection when mated provides dust-tight and waterproof sealing that most single-pole connectors lack; the 1000V AC / 1500V DC voltage rating exceeds the typical 600V maximum of traditional alternatives; silver-plated brass contacts deliver lower contact resistance (0.1 milliohms) than plain brass. These features, combined with TUV Rheinland certification and the phase-encoded blue housing for L3 identification, make PowerFit a generation ahead of traditional designs.
